Smart Logic Simulator 6.7.4 Apk Premium

You can create amazing logic circuits using logic gates flip-flops or hardware sensors from your smartphone. You can also use vibration engines or physical flashlights to create a range of inputs and outputs. You can also use proximity sensors light sensor, and many other sensors. Smart Logic Simulator's intuitive interface makes it easy to design circuits. The integrated circuit feature allows you to quickly scale up your projects. It lets you pack complex circuits into single, reusable parts and then import them all as many times you wish. The dependencies manager helps you organize all integrated circuits in one file, so that you can share your work easily with friends.

Liste of components available:

Gate - AND -

BUFFER Gate

NAND Gate

NOR Gate

- NO Gate

Gate - OR

XOR Gate

XNOR Gate

- Proximity sensor - This measures the object's proximity to the device's view screen.

- Charger detector - Returns high signals when the device is charged.

- Light sensor - Meases ambient light levels.

Magnetic Field Sensor: Measures ambient magnetic field.

- Seven Segment Display

- Seven Segment Display Decoder

- 5X7 Led Matrix Display

Light Bulb

Flashlight

- Speaker: Produces sound at a given frequency

The input signal can be high or low, and your device will vibrate.

- Clock (0.2Hz 0.5Hz 1Hz 2Hz 5Hz 10Hz)

- Pulse Button

- Toggle Button

- Constant High

- Lower Constant

The Notification Component creates a notification using a particular color.

SR Flip-Flop

JK Flip-Flop

- Flip-Flop

D Flip-Flop

SR Latch

- 16-1 Multiplexer

- 8-1 Multiplexer

4-1 Multiplexer

- Multiplexer 2-1

- 1-16 Demultiplexer

- 1-8 Demultiplexer

- 1-4 Demultiplexer

- 1-2 Demultiplexer

- Adder complete

Adder for half

- The Battery Level Meter

Are you a blogger? Tell your friends about Smart Logic Simulator. You can download images and resources at http://resources.smartlogicsimulator.com or contact us at mediaSmartLogicSimulator@gmail.com for any other information you might need.
